For more than 10 years, HuaYu has been a leading supplier of rare metals such as tantalum, niobium and its alloys. Relying on China’s abundant non-ferrous metal mine resources, we use exquisite metal processing technology to meet the needs of customers in the fields of chemical industry, optoelectronics, aviation and other fields for non-ferrous metal materials.
| Conventional tantalum and tantalum alloy foil and strip sizes | ||||
| Products | Dimensions (mm) | shape | ||
| thickness | width | length | ||
| Ta foil and strip | 0.0254 – 0.15 | 5 – 300 | 100 – 6000 | Aluminum foil, strip |
| Ta foil and strip | 0.15 – 0.5 | 50 – 1000 | 100 – 6000 | Aluminum foil, strip |
| Ta2.5W aluminum foil and strip | 0.02 – 0.09 | < 152 | ≥ 10000 | bring |
| Chemical requirements | |||||
| Content, Maximum, Weight % | |||||
| element | Electron Beam Casting/Vacuum Arc Casting R05200 Unalloyed Tantalum | Sintered R05400 unalloyed tantalum | Electron Beam Casting/Vacuum Arc Casting R05255 90% Tantalum 10% Tungsten | Electron Beam Casting/Vacuum Arc Casting R05252 97.5% Tantalum 2.5% Tungsten | Electron Beam Casting/Vacuum Arc Casting R05240 60% Tantalum 40% Niobium |
| C | 0.010 | 0.010 | 0.010 | 0.010 | 0.010 |
| O | 0.015 | 0.03 | 0.015 | 0.015 | 0.020 |
| N | 0.010 | 0.010 | 0.010 | 0.010 | 0.010 |
| H | 0.0015 | 0.0015 | 0.0015 | 0.0015 | 0.0015 |
| iron | 0.010 | 0.010 | 0.010 | 0.010 | 0.010 |
| mo | 0.020 | 0.020 | 0.020 | 0.020 | 0.020 |
| niobium | 0.100 | 0.100 | 0.100 | 0.50 | 35.0 – 42.0 |
| nickel | 0.010 | 0.010 | 0.010 | 0.010 | 0.010 |
| Four | 0.005 | 0.005 | 0.005 | 0.005 | 0.005 |
| titanium | 0.010 | 0.010 | 0.010 | 0.010 | 0.010 |
| W | 0.05 | 0.05 | 9.0 – 11.0 | 2.0 – 3.5 | 0.050 |
| Cyanide | remainder | remainder | remainder | remainder | remainder |
| Tantalum and Tantalum Alloys Foil Strip Sizes and Tolerances | ||||||
| thickness | Thickness tolerances | width | Width tolerances | length | Length tolerances | |
| Level 1 | Level 2 | |||||
| < 0.1 | ± 0.015 | ± 0.02 | 50 – 150 | ± 2.0 | 100 – 20000 | ± 2.0 |
| 0.1 – 0.2 | ± 0.015 | ± 0.02 | 50 – 240 | ± 2.0 | 100 – 20000 | ± 2.0 |
| > 0.2 – 0.3 | ± 0.02 | ± 0.03 | 50 – 650 | ± 2.0 | 100 – 6000 | ± 2.0 |
| > 0.3 – 0.5 | ± 0.03 | ± 0.04 | 50 – 650 | ± 2.0 | 100 – 6000 | ± 2.0 |
| > 0.5 – 0.8 | ± 0.04 | ± 0.06 | 50 – 650 | ± 2.0 | 100 – 6000 | ± 2.0 |
| > 0.8 – 1.0 | ± 0.06 | ± 0.08 | 50 – 650 | ± 2.0 | 100 – 6000 | ± 2.0 |
| > 1.0 – 1.5 | ± 0.08 | ± 0.12 | 50 – 650 | ± 3.0 | 100 – 6000 | ± 4.0 |
| > 1.5 – 2.0 | ± 0.12 | ± 0.16 | 50 – 650 | ± 3.0 | 100 – 4000 | ± 4.0 |
| > 2.0 – 3.0 | ± 0.16 | ± 0.18 | 50 – 650 | ± 5.0 | 100 – 4000 | ± 5.0 |
| > 3.0 – 4.0 | ± 0.18 | ± 0.20 | 50 – 650 | ± 5.0 | 100 – 3000 | ± 5.0 |
| > 4.0 – 6.0 | ± 0.20 | ± 0.24 | 50 – 650 | ± 5.0 | 100 – 2000 | ± 5.0 |
| We can produce according to the tolerances required by customers Products 。 | ||||||
| Rank and form | Annealing conditions | |||
| ultimate tensile strength, min， psi （MPa） |
Yield strength, min, psi (MPa) (2 % offset) |
Elongation, min, % (1-in. gauge length) |
||
| Non-alloyed tantalum （R05200） （R05400） Sheets, sheets and strips |
< 0.060 inches thick ≥ 0.060 in. thick |
30 000 （207） 25 000 （172） |
20 000 （138） 15 000 （103） |
20 30 |
| 90% Tantalum– 10% tungsten （R05255） |
sheets and tapes timber plates |
70 000 （482） 70 000 （482） |
60 000 （414） 55 000 （379） |
15 20 |
| 97.5 % Tantalum – 2.5% tungsten （R05252） |
< 0.125 inches thick ≥ 0.125 inches thick |
40 000 （276） 40 000 （276） |
30 000 （207） 22 000 （152） |
20 25 |
| 60% Tantalum– 40% niobium （R05240） |
< 0.060 inches thick ≥ 0.060 in. thick |
35 000 35 000 |
20 000 （138） 15 000 （103） |
25 25 |
Tantalum foil and tantalum strip applications
Tantalum foil can be used as a vacuum blast furnace for heating elements, thermal insulation components and loading containers. In the chemical industry, tantalum foil is used as boilers, heaters, coolers, various appliances, etc. It is widely used in the aerospace and medical device fields. Tantalum foil is also used in foil capacitors. For more than 10 years, Hoau has been a leading supplier of rare metals such as tantalum, niobium and its alloys. Relying on China’s abundant non-ferrous metal mine resources, we use exquisite metal processing technology to meet the needs of customers in the fields of chemical industry, optoelectronics, aviation and other fields for non-ferrous metal materials.
